Description

BUILT TO LAST

SOLO is our post base and wall mount bracket. It allows you to mount your structure to a surface or attach it to a wall. The flange has four oversized holes that enable you to secure your pergola to a deck, concrete, brick or any other surface you choose.

Check out the instructions and other products here

INCLUDED

  • 1x SOLO Pergola Post Base \ Wall Mount Brackets
  • 38mm Pan Head 304 S.S Timber screws with Black plastic head caps

NOT INCLUDED

  • Anchoring Hardware

FEATURES

  • 2.0mm Canadian Steel
  • Canadian Made Brackets
  • Weather-Ready: Coated in weather-resistant materials
  • Laser-cut, bent, and welded
  • All hardware, to secure to timber, is included
  • Packaged with 12G x 38mm Pan Head 304 S.S Wood screws with black plastic head caps
  • 5-year limited warranty
  • 8 fastening holes per side for attaching accessories

SPECS

  • Category: 90×90
  • Arm Opening (Interior): 91.7mm x 91.7mm
  • Arm Opening (Exterior): 95.3mm x 95.3mm
  • Arm Height: 177.8mm
  • Gauge: 2.0mm Canadian Steel
  • Overall Size (1 Pc.): LxWxH: 152.4mm x 152.4mm x 177.8mm
  • Colour: Black
  • Weight (1 Pc.): 2.3kg
  • Fastening Holes: 6.35mm
  • Flange: 25.4mm
  • Securing Holes: 9.525mm

TIPS

GENERAL

We recommend that you buy your timber from us obviously! But if you are interstate, it’s a good idea to take a bracket with you when you purchase your timber to test fit.

TIMBER

Our 90×90 brackets accommodate dressed timber, commonly called 4×4 DAR at local building supplies. The actual measure is 90mm x 90mm.

SCREWS

  • Each bracket only requires 2 screws per each side/set of eight holes.
  • Insert screws in holes closest to the timber.
  • Hardware to secure to timber is included.
  • Additional screws are available for purchase
